Reach Stackers

Empty container handling reach stackers
Range:

FT 10 50

  • LIFTING CAPACITY (ton): 10 – 8 – 5
  • STACKING HEIGHT: 6 x 8’6”
  • SPREADER: 20’ – 40’
  • WHEELBASE (mm): 5150

FT 13 50

  • LIFTING CAPACITY (ton): 13 – 9 – 5,5
  • STACKING HEIGHT: 6 x 8’6”
  • SPREADER: 20’ – 40’
  • WHEELBASE (mm): 5150

Laden Container Handling Reach Stackers
Range:

FT 45-60

  • LIFTING CAPACITY (ton): 45 – 32 – 16
  • STACKING HEIGHT: 5 x 9’6”
  • SPREADER: 20’ – 30’ – 40’
  • WHEELBASE (mm): 6000

FT 45-60 H

  • LIFTING CAPACITY (ton): 45 – 35 – 19
  • STACKING HEIGHT: 5 x 9’6”
  • SPREADER: 20’ – 30’ – 40’
  • WHEELBASE (mm): 6000

FT 45-65

  • LIFTING CAPACITY (ton): 45 – 36 – 20
  • STACKING HEIGHT: 5 x 9’6”
  • SPREADER: 20’ – 30’ – 40’
  • WHEELBASE (mm): 6500

FT 45-70

  • LIFTING CAPACITY (ton): 45 – 40 – 22
  • STACKING HEIGHT: 5 x 9’6”
  • SPREADER: 20’ – 30’ – 40’
  • WHEELBASE (mm): 7000

FT 45-75

  • LIFTING CAPACITY (ton): 45 – 45 – 26
  • STACKING HEIGHT: 5 x 9’6”
  • SPREADER: 20’ – 30’ – 40’
  • WHEELBASE (mm): 7500

FT 45-80

  • LIFTING CAPACITY (ton): 45 – 45 – 29
  • STACKING HEIGHT: 5 x 9’6”
  • SPREADER: 20’ – 30’ – 40’
  • WHEELBASE (mm): 8000

Intermodal Handling Reach Stackers
Range:

FT 45-60 PB

  • LIFTING CAPACITY (ton): 42 – 28 – 12
  • STACKING HEIGHT: 5 x 9’6”
  • SPREADER: 20’ – 30’ – 40’ with Piggy Back
  • WHEELBASE (mm): 6000

FT 45-60 H PB

  • LIFTING CAPACITY (ton): 45 – 31 – 14
  • STACKING HEIGHT: 5 x 9’6”
  • SPREADER: 20’ – 30’ – 40’ with Piggy Back
  • WHEELBASE (mm): 6000

FT 45-65 PB

  • LIFTING CAPACITY (ton): 45 – 31 – 14
  • STACKING HEIGHT: 5 x 9’6”
  • SPREADER: 20’ – 30’ – 40’ with Piggy Back
  • WHEELBASE (mm): 6500

FT 45-70 PB

  • LIFTING CAPACITY (ton): 45 – 36 – 18
  • STACKING HEIGHT: 5 x 9’6”
  • SPREADER: 20’ – 30’ – 40’ with Piggy Back
  • WHEELBASE (mm): 7000

FT 45-75 PB

  • LIFTING CAPACITY (ton): 45 – 45 – 23
  • STACKING HEIGHT: 5 x 9’6”
  • SPREADER: 20’ – 30’ – 40’ with Piggy Back
  • WHEELBASE (mm): 7500

FT 45-80 PB

  • LIFTING CAPACITY (ton): 45 – 45 – 26
  • STACKING HEIGHT: 5 x 9’6”
  • SPREADER: 20’ – 30’ – 40’ with Piggy Back
  • WHEELBASE (mm): 8000
